Place of Origin:
China
Brand Name:
DINGXING/DINGYI
Certification:
ISO/CE
Model Number:
DW-1650
DW-1650 5Ply Automatic Flute Laminator
Specifications:
Note: Specifications are subject to change without notice.
| Model | DW-1650 | |
| Max.Sheet Size(L*W, mm) | 1650*1450 | |
| Min.Sheet Size(L*W, mm) | 450*450 | |
| Thickness | Litho | 120~800gsm |
| Middle | 300-800gsm(single flute) | |
| Substrate |
300~800gsm (Up to 10mm Thick) A~N Single Layer/ 3/5Layers Corrugated Boards, Grey Paperboards and Cardboards |
|
| Accuracy | Within ±2 mm(Subject to Paper Quality and Specifications) | |
| Speed | 0 -5000sheets/hour(Subject to Paper Quality and Specifications) | |
| Power | AC~380V(30HP) | |
| Dimension: L*W*H(MM) | 1700*2650*2600 | |
| Weight(KG) | 9800 | |
Litho Paper Feeder
Gluing System
The adjustable glue roller system applies evenly on the corrugated board. The special chrome plated glue roller saves glue consumption with three sensors to prevent overflow. This recycles gluing system which refills the glue in the slot at both gluing rollers by electric glue controller. The gluing system prevents glue wasting for better performance of lamination.
Belt-Driven System
Cut down maintenance cost and lower the noise
Substrate Two Paper Feeders
The corrugated paper is attached and goes through the Spring plates by suction belt and make the corrugated board delivery smoothly. Newly designed assistance belt helps to do the perfect suction belt feeding jobs, especially for 3/5 /7 ply.
Servo motor Alignment and Timing System
Pressing Conveyor
Integrated with upper and lower pressing conveyor, all boards are pressed and dried naturally until they are laminated tightly without air bubbles.
Side Frames
Newly designed machine with strengthened frames ensures stability even at highest speed and long machine life. Independent roller wheels are easy to dismantle to ensure quick replacement.
Solid and durable precision casting hand wheels.
Electrical Control System
1. Operator Panel shows all operation buttons and functions. Auxiliary Operator Panels are located in the Feeder and Pressing Conveyor. The Counter calculates laminating sheets through photocell control and Fixed Speed Device ensures fixed running speed.
2. Electrical driven systems are Schneider and Fotek & Anly from Taiwan.
Sources of Main Parts
| Name | Place of Origin or Materials |
|
Taiwan(Joint venture) |
| 2.Lifting motor | Taiwan(Joint venture) |
| 3. Decelerator | Taiwan(Joint venture) |
| 4.Glue Pump | Taiwan(Joint venture) |
| 5.Clutch & Brake | Nikka from Taiwan |
| 6.Electrical drive | Schneider from France, Fotek,Anly from Taiwan |
| 7.Belts | Japan |
| 9. Air Blower | Taiwan(Joint venture) |
| 10.Air pump | Becker |
| 11.Servo motor | Yaskawa |
